Nanni offers a comprehensive range of propulsion engines and energy solutions for Workboats, Crew Transfer vessels, Passenger Ferries, Container Ships, Military vessels and oil tankers. Designed for many applications, our solutions ensure reliable energy and optimal performance at sea.
Through A R Peachment, Flow Marine are the exclusive agent for Nanni covering the Commercial & Governmental markets within the UK.
Marine Engines for Commercial & Military use
Know-how & technology
Nanni’s product line includes high-performance propulsion engines with power ranging from 30 to 2200 hp. In addition, soundproof power generators with a power supply ranging from 5 to 150 kWe. To complete your marine power solution, enjoy steering systems, instrument panels and interfaces.
Model presented: N9 CR2
Marine Generators for Commercial & Military use
Discover the Nanni range of generators dedicated to the commercial & military markets.
Soundless & Efficient
The Nanni generator range covers a power range from 5 kW to 800 kW's. Designed on Kubota, John Deere or MAN engine bases with Meccalte or Leyroy Somer alternators and output ranges covering 220/400v and 50/60Hz (only 50Hz shown below for UK however 60Hz available).
All generator sets are delivered assembled and ready to go, which can optionally include all installation related equipment, from fuel tanks to exhaust systems.
Within the capability of AR Peachment, we can supply the complete integrated solution which could for example include air conditioning and other marine ancillary equipment making the design and onboard systems much simpler, more efficient and cost effective.
Nanni Generators are available in three versions :
Frame chassis (W), Soundshield (C) and Soundless (S).
Frame Series
The Frame Generators allows the most versatile connections and can be adapted to a wide variety of situations inside the hull.
Soundshield Series
The sound enclosure is made of insulated panels in painted marine aluminium. With multiple access ports for all necessary connections and maintenance items including lifting visual access.
Soundless Series
The sound enclosure bears the same global properties as above, with even more reinforced soundproofing to ensure the best quietness possible in each and every environment.
Model presented: Q2400
Series | Model | Frequency | Phase | Power | Output | Data Sheet |
|---|---|---|---|---|---|---|
Type | Ref | Hz | φ | kW | Volts | - |
Q500 | 5CM50 | 50 | 1 | 5 | 230 | View pdf |
Q1100 | 8WM50 | 50 | 1 | 7.2 | 230 | |
8CM50 | 50 | 1 | 7.2 | 230 | ||
8CT50 | 50 | 0.8 | 7.2 | 230 / 400 | ||
8WT50 | 50 | 0.8 | 7.2 | 230 / 400 | ||
Q1500 | 10CM50 | 50 | 1 | 9.6 | 230 | View pdf |
10CT50 | 50 | 0.8 | 9.7 | 2x120 | ||
10WM50 | 50 | 1 | 9.6 | 230 | ||
10WT50 | 50 | 0.8 | 9.7 | 230 / 400 | ||
Q2400 | 18CM50 | 50 | 1 | 16.4 | 230 | View pdf |
20CM50 | 50 | 1 | 19 | 230 | ||
20CT50 | 50 | 0.8 | 19 | 230 | ||
18WM50 | 50 | 1 | 16.4 | 230 | ||
20WM50 | 50 | 1 | 19 | 2x120 | ||
20WT50 | 50 | 0.8 | 19 | 230 / 400 | ||
20SM50 | 50 | 1 | 19 | 230 | ||
20ST50 | 50 | 0.8 | 19 | 230 / 400 | ||
Q3300 | 23CM50 | 50 | 1 | 22.2 | 230 | View pdf |
23CT50 | 50 | 0.8 | 22.4 | 230 / 400 | ||
23WM50 | 50 | 1 | 22.2 | 230 | ||
23WT50 | 50 | 0.8 | 22.4 | 230 / 400 | ||
Q3600 | 30CM50 | 50 | 1 | 28.2 | 230 | View pdf |
30CT50 | 50 | 1 | 28.3 | 230 / 400 | ||
30WM50 | 50 | 1 | 28.2 | 230 | ||
30WT50 | 50 | 0.8 | 28.3 | 230 / 400 | ||
Q3800 | 36CM50 | 50 | 1 | 34.4 | 230 | View pdf |
36CT50 | 50 | 0.8 | 34.4 | 230 / 400 | ||
36WM50 | 50 | 1 | 34.4 | 230 | ||
36WT50 | 50 | 0.8 | 34.4 | 230 / 400 | ||
Q4500 | 45WT50 | 50 | 0.8 | 44 | 230 / 400 | View pdf |
60WT50 | 50 | 0.8 | 57.5 | 230 / 400 | ||
75WT50 | 50 | 0.8 | 72.8 | 230 / 400 | ||
85WT50 | 50 | 0.8 | 84.6 | 230 / 400 | ||
45ST50 | 50 | 0.8 | 44 | 230 / 400 | ||
60ST50 | 50 | 0.8 | 57.5 | 230 / 400 | ||
75ST50 | 50 | 0.8 | 72.8 | 230 / 400 | ||
85ST50 | 50 | 0.8 | 84.6 | 230 / 400 | ||
Q6800 | 100WT50 | 50 | 0.8 | 98.4 | 230 / 400 | View pdf |
125WT50 | 50 | 0.8 | 123 | 230 / 400 | ||
100ST50 | 50 | 0.8 | 98.4 | 230 / 400 | ||
125ST50 | 50 | 0.8 | 123 | 230 / 400 | ||
Q12000 | 177WT50 | 50 | 0.8 | 177 | 380 / 415 | |
TIER II | 262WT50 | 50 | 0.8 | 262 | 380 / 415 | |
355WT50 | 50 | 0.8 | 355 | 380 / 415 | ||
Q12000 | 278WT50 | 50 | 0.8 | 278 | 380 / 415 | |
TIER III | 340WT50 | 50 | 0.8 | 340 | 380 / 415 | |
Q24000 | 568WT50 | 50 | 0.8 | 568 | 230 / 400 | |
TIER II | 668WT50 | 50 | 0.8 | 668 | 230 / 400 | |
Q24000 | 568WT50 | 50 | 0.8 | 568 | 230 / 400 | |
TIER III | 668WT50 | 50 | 0.8 | 668 | 230 / 400 |
